The Coverslip Bottom

The outstanding characteristic of the ibidi µ-Slides, µ-Dishes, and µ-Plates is their thin coverslip bottom, which has excellent features for high-end microscopy applications. In comparison, the bottom of standard cell culture plastics is about 1 mm thick—which is more than 5 times the thickness of the coverslip and therefore not ideal for imaging.

ibidi offers labware with the ibidi Polymer Coverslip bottom or the ibidi Glass Coverslip bottom. For most applications, the ibidi Polymer Coverslip is the material of choice, as it offers optimal cell adherence combined with excellent optical properties. If your cells require a special coating, or if you are using a particular microscopy technique such as TIRF or super-resolution microscopy (STED, STORM), we recommend using the ibidi Glass Coverslip bottom.

Imaging chambers with the coverslip bottom are optimized mainly for use with inverted microscopy. You can find information about the compatibility of the surface materials with different microscopy techniques in our Surface Material Guide.

ibidi Blog Article

Do you want to know the full story about the ibidi Polymer Coverslip, including its discovery, as well as optical and cell culture properties?
Find out in the ibidi Blog article More Than Plastic: The ibidi Polymer Coverslip by Tina Freisinger (ibidi GmbH).

surfaces_polymer_grey_72.jpg surfaces_glass_1_5H_grey_72.jpg surfaces_glass_1_5_grey_72.jpg surfaces_glassslide_grey_72.jpg
#1.5 ibidi Polymer Coverslip #1.5H ibidi Glass Coverslip #1.5 glass coverslip Standard glass slide*
Bottom thickness 180 µm (+10/–5 µm) 170 µm (+/–5 µm) 170 µm (+20/–10 µm) 1 mm
Bottom material Polymer D 263 M Schott high
precision glass
D 263 M Schott high
precision glass
Gas permeability Yes No No No

* With the 3 Well | 8 Well | 12 Well Chamber Slides, removable, ibidi provides self-adhesive, removable silicone chambers that are mounted on a standard glass slide. They are suitable for upright and inverted microscopy and enable long-term storage of samples after immunofluorescence staining.

surfaces_polymer_72.jpgibidi Polymer Coverslip

The ibidi Polymer Coverslip, which is our most recommended surface, is a thin plastic coverslip that forms the bottom of most μ-Slides, μ-Dishes, and μ-Plates. With a standard No. 1.5 coverslip thickness of 180 µm (+10/–5 µm) and immersion oil compatibility, it meets all optical requirements for microscopes and is suitable for various imaging techniques (e.g., phase contrast, DIC, widefield fluorescence, confocal microscopy, two-photon microscopy, FRAP, FRET, FLIM, or LSFM). Unlike glass, the ibidi Polymer Coverslip is gas-permeable. The ibidi Polymer Coverslip provides optimal growth conditions for various cell-based assays and cell types and is available with different treatments or coatings (ibiTreat, Bioinert, Collagen IV, Poly-L-Lysine). You can find more information about the coatings in our Coating Guide.


surfaces_glass_1_5H_72.jpgGlass Coverslip Bottom

ibidi offers specialized glass bottom labware with a borosilicate coverglass bottom. ibidi developed these glass surfaces specifically for TIRF, super-resolution microscopy, and single molecule microscopy. The glass bottoms are completely gas-proof and do not allow for any gas exchange.

To provide the highest quality necessary for modern, high-performance microscope objectives, only D 263 M Schott glass coverslips with a thickness range of 170 μm (+/–5 μm) are used. This thickness is also known as #1.5H (high performance).

The ibidi glass bottom labware is available in the following formats:


The ibidi Glass Bottom Dish 35 mm is produced by using a standard #1.5 glass coverslip with a thickness of 170 µm (+20 µm/–10 µm). This glass bottom material fulfills the needs of all standard applications where a cost-effective coverslip is required.

Please note:
In principle, glass bottoms are suitable for direct cell culture. However, to promote cell attachment, a surface coating might be required prior to cell seeding.

Fun Fact: Why So Many ibidi Products Have a "µ" in Their Names

µ is a lowercase letter in the Greek alphabet ("Mu"). In the metric system, the unit prefix "µ" is used as a symbol for "micro" and represents one millionth (10-6).
Here are some reasons why the µ found its way into so many ibidi product names:

  • Typically, eukaryotic cells are 10–100 micrometers in diameter.
  • To put the cells into focus, we offer solutions for different microscopy techniques.
  • The principle of the ibidi µ-Slides, µ-Dishes, and µ-Plates is the thin coverslip bottom with a thickness of 180 micrometers.
  • Last, but not least, our physicists love to use Greek letters such as "µ".

Read on and learn more about the ibidi Chamber Surfaces or the Chamber Geometry.
